· Tri-dividing frequency, two-way drive screen main channel movie speaker system
· low-distortion sound waves guide tube, to guarantee tone quality plump
· Installation is simple and convenient

CPS4216 and CPS4216C three-way frequency speaker systems are perfect for large-sized digital stereo movie halls with 400~800 seats and projecting distance between 24m and 30mm. The bass system consists of two PW1503 low-pitch units and direct-coupled boxes; the mid/treble system consists of PH2321 biradial constant directivity horns; the midrange is PW1006 IF speaker unit; the treble unit is PD2113 drive. CPS4216C has a built-in power prescaler in IF/HF unit.

Technical parameter	CPS4216
Frequency response	31.5-20KHz(-6dB)
Coverage angles	H:90°, V:20°(up)~30°(down)
Directivity factor(Q)	10
Directivity index	10dB
	Woffer	Medium frequency Speaker		Tweeter
Unit model	2×PW1503	PW1006&PH2321		PD2113&PH2321
transducer	Two Φ 381mm high efficiency low frequency speakers, Φ 100 mm KAPTON skeleton voice coil,, Φ 220 mm strontium qualitative magnets.	Φ 300mm high efficiency low frequency speakers, Φ 75 mm KAPTON skeleton voice coil,, Φ 160 mm strontium qualitative magnets.		Φ 72 mm titanium coating compression drive structure, KAPTON skeleton rectangular section copper coated aluminium wire voice coil,, Φ 156 mm strontium qualitative magnets.
Nominal impedance	4Ω	8Ω	8Ω
Sensitivity 1w/1m	103dB	106dB	112dB
Rated Input Power	800W	300W	150W
Maximum input power	1600W	600W	300W
Maximum SPL	135dB	132dB	136.8dB
Crossover frequency	350/2500
Connection	2 metal connecting terminals, the biggest standard wire can be used is 6 mm2.	2 metal connecting terminals, the biggest standard wire can be used is 6 mm2.
Dimensions	1910mm×760mm ×450mm (H×W×D)
Net weight	89kg

PS: [1] Maximum input power test meets IEC268-5 recommend standard, 50 Hz-20 KHz bandwidth, 6 db signal peak factor.
